Figure-8 outdoor Aerial installation optic fiber cable

Description:

The fibers,  250μm , are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire locates in the center of core as a metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular cable core.  this part of cable accompanied with the stranded wires as the supporting part are completed with a polyethylene (PE) sheath to be figure 8 structure.

Characteristics:

       High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.

       Good mechanical and temperature performance

       High strength loose tube that is hydrolysis resistant

       Special tube filling compound ensure a critical protection of fiber

       The following measures are taken to ensure the cable watertight:

       Steel wire used as the central strength member

       Loose tube filling compound

       100% cable core filling

Standards:

        GYTC8Y cable complies with Standard YD/T 1155-2001 as well as IEC 60794-1.

Optical Characteristics:

Technical Parameters:
